TD SERİSİ (25 BAR)
| PRODUCT CODE | MODEL | VOLUME (Liters) | MAXIMUM OPERATING PRESSURE | DIAMETER (mm) | HEIGHT (mm) | CONNECTION DIAMETER | MEMBRANE |
| 0151,1004 | TD 100/25 * | 100 | 25 Bar | 470 | 900 | 1" | EPDM |
| 0151,1005 | TD 150/25 * | 150 | 26 Bar | 640 | 970 | 1" | EPDM |
| 0151,1006 | TD 200/25 * | 200 | 27 Bar | 640 | 1080 | 1" | EPDM |
| 0151,1007 | TD 300/25 * | 300 | 28 Bar | 640 | 1240 | 1¹ / 2" | EPDM |
| 0151,1008 | TD 500/25 * | 500 | 29 Bar | 800 | 1400 | 1¹ / 2" | EPDM |
| 0151,1009 | TD 750/25 * | 750 | 30 Bar | 800 | 1700 | 2" | EPDM |
| 0151,1010 | TD 1000/25 * | 1000 | 31 Bar | 800 | 2200 | 2" | EPDM |
Our ( * ) marked tanks are manometer.
FEATURES
